X5 Centrifugal Series Air Curtain 20m/s
1.Through high-speed centrifugal airflow, an invisible wind curtain barrier is formed to realize indoor and outdoor environmental isolation, and simultaneously solve the three major pain points of commercial places: energy consumption control (energy saving of more than 30%), hygiene protection (blocking PM2.5/flying insects), and temperature management (cold and hot air isolation).
2.Dual-mode intelligent control, optional remote control (30m remote control) or manual panel, support 2 wind speeds (high speed 8m/s/low speed 5m/s).
3.The use of all-copper winding motor (IP55 protection level) with centrifugal impeller with a lifespan of up to 50,000 hours can reduce the frequency of equipment replacement and reduce operation and maintenance costs.
4.Dynamic airflow optimization, automatic adjustment of the air outlet angle according to the door height (1.5-3 meters adaptive), wind speed uniformity up to ±5%, to ensure effective coverage and eliminate airflow dead corners.
DESCRIPTION & FEATURES
The X5 centrifugal pure white air curtain maintains environmental separation with a light flow of air, remote controller, that not only results in lowered energy costs but also helps in preventing air borne contaminants & deterring flying insects from moving from one open space to another-enhancing sanitation & hygiene. Applications Entrance of Industries, Restaurants, Offices, Malls & other commercial places.
（Mobile terminal：Slide the picture to the right to see more）
| Model | Voltage (V~Hz) | Power (W) | Airflow (m³/h) | Speed (m/s) | Noise (dB) | Weight (kgs) | Dimensions (mm) |
|---|---|---|---|---|---|---|---|
| FM-4509-L/Y | 220-50 | 230 | 1100 | 16 | 50 | 13 | 900x215x230 |
| FM-4512-L/Y | 220-50 | 290 | 1500 | 16 | 52 | 15.5 | 1200x215x230 |
| FM-4515-L/Y | 220-50 | 380 | 1900 | 16 | 53 | 20 | 1500x215x230 |
| FM-4518-L/Y | 220-50 | 450 | 2280 | 16 | 54 | 23.5 | 1800x215x230 |
